Микроэлектроника – контрольно-измерительные приборы и РЧ-компоненты: Серия HPAS S-диапазон

Твердотельные усилители мощности S-диапазон

Для увеличения картинки наведите мышкой

Избранное

Наличие: По запросу

По запросу

Teledyne Paradise Datacom

Teledyne Paradise Datacom, a division of Teledyne Defense Electronics, LLC, designs, manufactures and sells satellite modems, solid state power amplifiers (SSPA), low noise amplifiers (LNA), block up converters (BUC) and associated redundancy subsystems. We deliver satellite communications products around the world.

Teledyne Paradise Datacom Background
Paradise Datacom Ltd. was founded in 1988 in the United Kingdom. It specialised in the design and manufacture of IBS/IDR framing units and… подробнее

Обзор Характеристики Модели и опции Библиотека Отзывы (0)

Обзор

Свернуть Развернуть

Основные возможности и технические характеристики

Indoor Rack Mount

GaAs Solid State Power Amplifier

3RU Rack Height

Description

Teledyne Paradise Datacom’s Indoor, Compact Rack Mount (CRM) series Solid State Power Amplifiers represent the latest in High Power Microwave Amplifier Technology. The SSPA chassis achieves the highest power density in the industry along with enhanced maintainability.

The power supply, fan trays and controller card connector plate are all removable for easy maintenance. At 24” deep, and only 3RU high, this chassis is perfect for SNG applications, or other configurations where rack space is at a premium.

The SSPA front panel features an easy-to-navigate display and menu structure. Dedicated LEDs are provided for alarm condition indication.

Teledyne Paradise Datacom rack mount power amplifiers have a wide range of monitor and control functionality, including:

RS-232/RS-485 (4-wire) serial communication
Ethernet port supporting UDP, SNMP and web browser-based control
Form C contacts for output monitor ports and optoisolated input ports
Free Windows M&C software
Variety of third party M&C drivers available

FEATURES

Power Levels to:
300W C-Band;
200W X-Band;
150W Ku-Band
Removable Power Supply,
Fan Tray and Monitor &
Control Assembly
Ethernet Port
RF Output Sample Port
20 dB Gain Adjustment
CE Compliant
Universal, Power Factor
Corrected Power Supply
Built-in 1:1 Redundancy
Control
Built-in Maintenance
Switch Controller

OPTIONS

Remote Control Panel
L-Band Input operation
Reflected Power Monitor
Input Sample Port
1RU Redundant Power
Exhaust Duct Adapters
Redundant Systems
Phase Combined Systems

Свернуть Развернуть

Комплектация

Узнайте по тел.: +7 (495) 105 96 88
Напишите нам письмо: info@micro-electronics.ru

Свернуть Развернуть

Сведения о реестре СИ

Реестр СИ не требуется

Характеристики

Загрузить технические характеристики

Available Frequency Plans
Band	Frequency Plan	IF Input	LO Frequency	RF Output
C	Sub-Band “A”	950 - 1525 MHz	4.900 GHz	5.850 - 6.425 GHz
C	Sub-Band “B”	950 - 1825 MHz	4.900 GHz	5.850 - 6.725 GHz
C	Sub-Band “C”	950 - 1870 MHz	4.800 GHz	5.750 - 6.670 GHz
C	Sub-Band “E”	950 - 1250 MHz	5.475 GHz	6.425 - 6.725 GHz
C	Sub-Band “F”	950 - 1250 MHz	5.775 GHz	6.725 - 7.025 GHz
C	Sub-Band “L”	950 - 1550 MHz	3.450 GHz	4.400 - 5.000 GHz
X	Sub-Band “A”	950 - 1450 MHz	6.950 GHz	7.900 - 8.400 GHz
Ku	Sub-Band “A”	950 - 1450 MHz	13.050 GHz	14.00 - 14.50 GHz
Ku	Sub-Band “B”	950 - 1700 MHz	12.800 GHz	13.75 - 14.50 GHz
Ku	Sub-Band “F”	950 - 1450 MHz	11.800 GHz	12.75 - 13.25 GHz
Specifications, L-Band SSPAs
PARAMETER		NOTES	LIMITS	UNITS
Frequency Range		Frequency selection “A”	1.750 to 1.850	GHz
Output Power Typical, Psat Guaranteed minimum, PLinear ¹		HPAL3050ARXXXXPG2 HPAL3100ARXXXXPG2 HPAL3200ARXXXXPG2 HPAL3300ARXXXXPG2 HPAL3400ARXXXXPG2 HPAL3500ARXXXXPG2 HPAL3600ARXXXXPG2 HPAL3800ARXXXXPG2 HPAL310KARXXXXPG2	Psat / PLinear 47.0 (50) / 44.0 (25) 50.0 (100) / 47.0 (50) 53.0 (200) / 50.0 (100) 54.8 (300) / 51.8 (150) 56.0 (400) / 53.0 (200) 57.0 (500) / 54.0 (250) 57.8 (600) / 54.8 (300) 59.0 (800) / 56.0 (400) 60.0 (1000) / 57.0 (500)	dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W)
Power Requirements Line Frequency Line Power (Voltage) (typical @ 220 VAC)		power factor HPAL3050ARXXXXPG2 HPAL3100ARXXXXPG2 HPAL3200ARXXXXPG2 HPAL3300ARXXXXPG2 HPAL3400ARXXXXPG2 HPAL3500ARXXXXPG2 HPAL3600ARXXXXPG2 HPAL3800ARXXXXPG2 HPAL310KARXXXXPG2	.98 47 to 63 Psat / PLinear 400 / 300 (90 to 265) 500 / 400 (90 to 265) 800 / 700 (90 to 265) 1300 / 1000 (180 to 265) ² 2000 / 1300 (180 to 265) ² 2100 / 1500 (180 to 265) ² 2200 / 1700 (180 to 265) ² 2500 / 2000 (180 to 265) ² 4000 / 3500 (180 to 265) ²	Hz W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC)
Receive Band Noise Power Density		without optional filter with optional filter	-95 -155	dBW / 4 KHz dBW / 4 KHz
Specifications, S-Band SSPAs
PARAMETER		NOTES	LIMITS	UNITS
Frequency Range		Frequency selection “G” Frequency selection “A” Frequency selection “B”	1.750 to 2.120 ³ 2.020 to 2.120 2.200 to 2.300	GHz GHz GHz
Output Power Typical, Psat Guaranteed minimum, PLinear ¹		HPAS3050ARXXXXPG2 HPAS3100ARXXXXPG2 HPAS3200ARXXXXPG2 HPAS3300ARXXXXPG2 HPAS3400ARXXXXPG2 HPAS3500ARXXXXPG2 HPAS3600ARXXXXPG2 HPAS3800ARXXXXPG2 HPAS310KARXXXXPG2	Psat / PLinear 47.0 (50) / 44.0 (25) 50.0 (100) / 47.0 (50) 53.0 (200) / 50.0 (100) 54.8 (300) / 51.8 (150) 56.0 (400) / 53.0 (200) 57.0 (500) / 54.0 (250) 57.8 (600) / 54.8 (300) 59.0 (800) / 56.0 (400) 60.0 (1000) / 57.0 (500)	dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W)
Power Requirements Line Frequency Line Power (Voltage) (typical @ 220 VAC)		power factor HPAS3050ARXXXXPG2 HPAS3100ARXXXXPG2 HPAS3200ARXXXXPG2 HPAS3300ARXXXXPG2 HPAS3400ARXXXXPG2 HPAS3500ARXXXXPG2 HPAS3600ARXXXXPG2 HPAS3800ARXXXXPG2 HPAS310KARXXXXPG2	.98 47 to 63 Psat / PLinear 400 / 300 (90 to 265) 500 / 400 (90 to 265) 800 / 700 (90 to 265) 1300 / 1000 (180 to 265) ² 2000 / 1300 (180 to 265) ² 2100 / 1500 (180 to 265) ² 2200 / 1700 (180 to 265) ² 2500 / 2000 (180 to 265) ² 4000 / 3500 (180 to 265) ²	Hz W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC)
Receive Band Noise Power Density		without optional filter with optional filter	-95 -155	dBW / 4 KHz dBW / 4 KHz
Note 1: PLinear = maximum output power at which third order intermodulation products < -25 dBc (for two tones separated by 5 MHz) or spec-tral regrowth on a single QPSK at 1.5 x symbol rate or OQPSK at 1.0 x symbol rate is < -30 dBc. Note 2: For 90 to 180 VAC operation, consult factory. Note 3: Not available at 500W or 1000W (10K).
Specifications, C-Band SSPAs
PARAMETER		NOTES	LIMITS	UNITS
Frequency Range		Frequency selection “L” Frequency selection “H” Frequency selection “C” ³ Frequency selection “A” Frequency selection “B” ³ Frequency selection “D”	4.400 to 5.000 5.715 to 5.790 5.750 to 6.670 5.850 to 6.425 5.850 to 6.725 6.425 to 7.025	GHz GHz GHz GHz GHz GHz
Output Power Typical, Psat Guaranteed minimum, PLinear ¹		HPAC3050ARXXXXPG2 HPAC3100ARXXXXPG2 HPAC3150ARXXXXPG2 HPAC3200ARXXXXPG2 HPAC3300ARXXXXPG2 HPAC3400ARXXXXPG2 HPAC3650ARXXXXPG2 HPAC3800ARXXXXPG2 HPAC310KARXXXXPG2	Psat / PLinear 47.0 (50) / 44.0 (25) 50.0 (100) / 47.0 (50) 51.8 (150) / 48.8 (75) 53.0 (200) / 50.0 (100) 54.8 (300) / 51.8 (150) 56.0 (400) / 53.0 (200) 58.1 (650) / 55.1 (325) 59.0 (800) / 56.0 (400) 60.0 (1000) / 57.0 (500)	dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W)
Power Requirements Line Frequency Line Power (Voltage) (typical @ 220 VAC)		power factor HPAC3050ARXXXXPG2 HPAC3100ARXXXXPG2 HPAC3150ARXXXXPG2 HPAC3200ARXXXXPG2 HPAC3300ARXXXXPG2 HPAC3400ARXXXXPG2 HPAC3650ARXXXXPG2 HPAC3800ARXXXXPG2 HPAC310KARXXXXPG2	.98 47 to 63 Psat / PLinear 500 / 400 (90 to 265) 600 / 500 (90 to 265) 1000 / 800 (90 to 265) 1100 / 880 (90 to 265) 1500 / 1300 (180 to 265) ² 1800 / 1600 (180 to 265) ² 3300 / 2800 (180 to 265) ² 4000 / 3500 (180 to 265) ² 4500 / 3700 (180 to 265) ²	Hz W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC)
Receive Band Noise Power Density		without filter	-155	dBW / 4 kHz
Specifications, X-Band SSPAs
PARAMETER		NOTES	LIMITS	UNITS
Frequency Range		Frequency selection “F” Frequency selection “D” Frequency selection “A”	7.10 to 7.40 7.70 to 8.40 7.90 to 8.40	GHz GHz GHz
Output Power Typical, Psat Guaranteed minimum, PLinear ¹		HPAX3300ARXXXXPG2 HPAX3400ARXXXXPG2 HPAX3650ARXXXXPG2 HPAX3800ARXXXXPG2	Psat / PLinear 54.8 (300) / 51.8 (150) 56.0 (400) / 53.0 (200) 58.1 (650) / 55.1 (325) 59.0 (800) / 56.0 (400)	dBm (W) dBm (W) dBm (W) dBm (W)
Power Requirements Line Frequency Line Power (Voltage) (typical @ 220 VAC)		power factor Line frequency HPAX3300ARXXXXPG2 HPAX3400ARXXXXPG2 HPAX3650ARXXXXPG2 HPAX3800ARXXXXPG2	.98 47 to 63 Psat / PLinear 1500 / 1300 (180 to 265) ² 2000 / 1700 (180 to 265) ² 3300 / 2800 (180 to 265) ² 4000 / 3500 (180 to 265)	Hz W (VAC) W (VAC) W (VAC) W (VAC)
Receive Band Noise Power Density		without optional filter with optional filter	-85 -155	dBW / 4 kHz dBW / 4 kHz
Note 1: PLinear = maximum output power at which third order intermodulation products < -25 dBc (for two tones separated by 5 MHz) or spec-tral regrowth on a single QPSK at 1.5 x symbol rate or OQPSK at 1.0 x symbol rate is < -30 dBc. Note 2: For 90 to 180 VAC operation, consult factory. Note 3: Output power decreases over the extended portion of the frequency range. Both Psat and PLinear de-rate by 1 dB from 5.85 to 5.75 GHz and from 6.425 to 6.725 GHz.
Specifications, Ku-Band SSPAs
PARAMETER		NOTES	LIMITS	UNITS
Frequency Range		Frequency selection “F” Frequency selection “B” Frequency selection “A” Frequency selection “C” Frequency selection “D”	12.75 to 13.25 13.75 to 14.50 14.00 to 14.50 14.50 to 14.70 15.10 to 15.40	GHz GHz GHz GHz GHz
Output Power Typical, Psat Guaranteed minimum, PLinear ¹		HPAK3050ARXXXXPG2 HPAK3080ARXXXXPG2 HPAK3100ARXXXXPG2 HPAK3150ARXXXXPG2 HPAK3200ARXXXXPG2 HPAK3250ARXXXXPG2 HPAK3300ARXXXXPG2 HPAK3400ARXXXXPG2 HPAK3500ARXXXXPG2 HPAK3600ARXXXXPG2	Psat / PLinear 47.0 (50) / 44.0 (25) 49.0 (80) / 46.0 (40) 50.0 (100) / 47.0 (50) 51.8 (150) / 48.8 (75) 53.0 (200) / 50.0 (100) 54.0 (250) / 51.0 (125) 54.8 (300) / 51.8 (150) 56.0 (400) / 53.0 (200) 57.0 (500) / 54.0 (250) 57.8 (600) / 54.8 (300)	dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W) dBm (W)
Power Requirements Line Frequency Line Power (Voltage) (typical @ 220 VAC)		power factor Line frequency HPAK3050ARXXXXPG2 HPAK3080ARXXXXPG2 HPAK3100ARXXXXPG2 HPAK3150ARXXXXPG2 HPAK3200ARXXXXPG2 HPAK3250ARXXXXPG2 HPAK3300ARXXXXPG2 HPAK3400ARXXXXPG2 HPAK3500ARXXXXPG2 HPAK3600ARXXXXPG2	.98 47 to 63 Psat / PLinear 600 / 500 (90 to 265) 730 / 585 (90 to 265) 900 / 750 (90 to 265) 1000 / 850 (90 to 265) 1200 / 920 (90 to 265) 1500 / 1000 (180 to 265) ² 2000 / 1500 (180 to 265) ² 2500 / 1700 (180 to 265) ² 3000 / 2000 (180 to 265) ² 3200 / 2500 (180 to 265) ²	Hz W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC) W (VAC)
Receive Band Noise Power Density³			-155	dBW / 4 kHz
Note 1: PLinear = maximum output power at which third order intermodulation products < -25 dBc (for two tones separated by 5 MHz) or spec-tral regrowth on a single QPSK at 1.5 x symbol rate or OQPSK at 1.0 x symbol rate is < -30 dBc. Note 2: For 90 to 180 VAC operation, consult factory. Note 3: All Ku-Band SSPAs are fitted with a receive band reject bulkhead filter, standard. An optional pressure window is available.

Производитель

Teledyne Paradise Datacom

Модели и опции

	Товар

	Модели и Опции	Описание	Цена	Заказать

Модели

HPAS3050ARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 47.0 (50)/PLinear 44.0 (25) дБм(Вт)	По запросу	- шт +
HPAS3100ARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 50.0 (100)/PLinear 47.0 (50) дБм(Вт)	По запросу	- шт +
HPAS3200ARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 53.0 (200)/PLinear 50.0 (100) дБм(Вт)	По запросу	- шт +
HPAS3300ARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 54.8 (300)/PLinear 51.8 (150) дБм(Вт)	По запросу	- шт +
HPAS3400ARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 56.0 (400)/PLinear 53.0 (200) дБм(Вт)	По запросу	- шт +
HPAS3500ARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 57.0 (500)/PLinear 54.0 (250) дБм(Вт)	По запросу	- шт +
HPAS3600ARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 57.8 (600)/PLinear 54.8 (300) дБм(Вт)	По запросу	- шт +
HPAS3800ARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 59.0 (800)/PLinear 56.0 (400) дБм(Вт)	По запросу	- шт +
HPAS310KARXXXXPG2	Твердотельные усилители мощности S-Band SSPAs, Psat 60.0 (1000)/PLinear 57.0 (500) дБм(Вт)	По запросу	- шт +
HPAS5500ARXXXXPG	Твердотельные усилители мощности S-Band SSPAs, Psat 57.0 (500)/PLinear 54.0 (250) дБм(Вт)	По запросу	- шт +
HPAS5600ARXXXXPG	Твердотельные усилители мощности S-Band SSPAs, Psat 57.8 (600)/PLinear 54.8 (300) дБм(Вт)	По запросу	- шт +
HPAS5800ARXXXXPG	Твердотельные усилители мощности S-Band SSPAs, Psat 59.0 (800)/PLinear 56.0 (400) дБм(Вт)	По запросу	- шт +
HPAS510KARXXXXPG	Твердотельные усилители мощности S-Band SSPAs, Psat 60.0 (1000)/PLinear 57.0 (500) дБм(Вт)	По запросу	- шт +
HPAS512KARXXXXPG	Твердотельные усилители мощности S-Band SSPAs, Psat 60.8 (1200)/PLinear 57.8 (600) дБм(Вт)	По запросу	- шт +
HPAS516KARXXXXPG	Твердотельные усилители мощности S-Band SSPAs, Psat 62.0 (1600)/PLinear 59.0 (800) дБм(Вт)	По запросу	- шт +
HPAS520KARXXXXPG	Твердотельные усилители мощности S-Band SSPAs, Psat 63.0 (2000)/PLinear 60.0 (1000) дБм(Вт)	По запросу	- шт +
HPAS2600AHXXXXXG	Твердотельные усилители мощности S-Band Output Power Levels, Psat 58.0 (600)/PLinear 55.0 (300) дБм(Вт)	По запросу	- шт +
HPAL2800AHXXXXXG	Твердотельные усилители мощности S-Band Output Power Levels, Psat 59.0 (800)/PLinear 56.0 (400) дБм(Вт)	По запросу	- шт +
HPAL210KAHXXXXXG	Твердотельные усилители мощности S-Band Output Power Levels, Psat 60.0 (1000)/PLinear 57.0 (500) дБм(Вт)	По запросу	- шт +
HPAS2050ACXXXXXG	Твердотельные усилители мощности S-Band SSPAs, Psat 47.5 (56)/Plinear 43.0 (20) дБм(Вт)	По запросу	- шт +
HPAS2100ACXXXXXG	Твердотельные усилители мощности S-Band SSPAs, Psat 50.0 (100)/Plinear 47.0 (50) дБм(Вт)	По запросу	- шт +
HPAS2200ACXXXXXG	Твердотельные усилители мощности S-Band SSPAs, Psat 53.0 (200)/Plinear 50.0 (100) дБм(Вт)	По запросу	- шт +
HPAS2300ACXXXXXG	Твердотельные усилители мощности S-Band SSPAs, Psat 54.8 (300)/Plinear 51.8 (150) дБм(Вт)	По запросу	- шт +
HPAS2400ACXXXXXG	Твердотельные усилители мощности S-Band SSPAs, Psat 56.0 (400)/Plinear 53.0 (200) дБм(Вт)	По запросу	- шт +
HPAS2500ACXXXXXG	Твердотельные усилители мощности S-Band SSPAs, Psat 57.0 (500)/Plinear 54.0 (250) дБм(Вт)	По запросу	- шт +
