Французская компания SIEPEL, была созданна в 1986 году. Штаб-квартира и производство компании находится в La Trinité-Sur-Mer в Британи.
Компания SIEPEL разрабатывает и производит электромагнитные поглотители и экранированные помещения для различных областей электромагнитной совместимости (ЭМС), для измерений микроволновых / антенных систем, а также кибербезопасности различных областей применения: ПЭМИН (TEMPEST), EMP, HEMP, HIRF.
SIEPEL – известный европейский производитель безэховых камер, предназначенных для тестирования на… подробнее

![]() |
OUR STRENGTHS |
![]() |
![]() |
MODULAR SHIELDING Self-standing structure up to 18 (40) GHz Steele stiffeners |
![]() |
OPTIMISED ABSORBER LINING Ferrite absorbers (walls and ceiling) Hybrid pyramidal absorbers (partial lining walls and ceiling) Removable pyramidal absorbers for immunity (floor) |
![]() |
DOOR Manual single leaf swing door Clearance 1.2 x 2.1 m / 3.9 x 6.8 ft with interlock switch |
![]() |
RAISED FLOOR With ground plane |
![]() |
WALL PANELS Penetration panel including coaxial feedthroughs and waveguides |
![]() |
TURNTABLE Diameter 1.2 m / 3.9 ft Max payload 500 kg / 1102,3 lbs |
![]() |
VENTILATION Honeycomb air vents 300 x 300 mm / 1 ft x 1 ft up to 18 (40) GHz |
![]() |
PROJECT REALISATION Project management Technical design & study On-site installation |
![]() |
POWER DISTRIBUTION Power filter single-phase 32 A - 50/60 Hz Power filter three-phase 32 A - 50/60 Hz Electrical package: power distribution, lighting |
![]() |
PERFORMANCE VERIFICATION Shielding effectiveness at 900 MHz at critical locations |
AVAILABLE OPTIONS
› Extended shielding performances up to 40 GHz
› Shielded control and amplifier rooms
› Plastic paint for pyramidal absorbers with wide range of colors
› Other types and dimensions of doors
› Electrically-assisted door latching/unlatching
› Antenna positioners
› Floor hatches with connection points
› Additional power filters, data filters and special feedthroughs
› CCTV / Audio monitoring systems
› Fire detection systems
› On request, some measurements can be accredited ISO 17025 (accreditation number 1-6220).
› Military / Automotive / RadioCom standards compliance
› Many other options on demand

![]() |
OUR STRENGTHS |
![]() |
![]() |
MODULAR SHIELDING Self-standing structure up to 18 (40) GHz Steele stiffeners |
![]() |
OPTIMISED ABSORBER LINING Ferrite absorbers (walls and ceiling) Hybrid pyramidal absorbers (partial lining walls and ceiling) Removable pyramidal absorbers for immunity (floor) |
![]() |
DOOR Manual single leaf swing door Clearance 1.2 x 2.1 m / 3.9 x 6.8 ft with interlock switch |
![]() |
RAISED FLOOR With ground plane |
![]() |
WALL PANELS Penetration panel including coaxial feedthroughs and waveguides |
![]() |
TURNTABLE Diameter 1.2 m / 3.9 ft Max payload 500 kg / 1102,3 lbs |
![]() |
VENTILATION Honeycomb air vents 300 x 300 mm / 1 ft x 1 ft up to 18 (40) GHz |
![]() |
PROJECT REALISATION Project management Technical design & study On-site installation |
![]() |
POWER DISTRIBUTION Power filter single-phase 32 A - 50/60 Hz Power filter three-phase 32 A - 50/60 Hz Electrical package: power distribution, lighting |
![]() |
PERFORMANCE VERIFICATION Shielding effectiveness at 900 MHz at critical locations |
AVAILABLE OPTIONS
› Extended shielding performances up to 40 GHz
› Shielded control and amplifier rooms
› Plastic paint for pyramidal absorbers with wide range of colors
› Other types and dimensions of doors
› Electrically-assisted door latching/unlatching
› Antenna positioners
› Floor hatches with connection points
› Additional power filters, data filters and special feedthroughs
› CCTV / Audio monitoring systems
› Fire detection systems
› On request, some measurements can be accredited ISO 17025 (accreditation number 1-6220).
› Military / Automotive / RadioCom standards compliance
› Many other options on demand
По тел.: +7 (495) 105 96 88 или
Написать нам письмо: info@micro-electronics.ru
По тел.: +7 (495) 105 96 88 или
Написать нам письмо: info@micro-electronics.ru
Номер в Госреестре |
Наименование СИ |
Обозначение типа СИ |
Изготовитель |
Срок свидетельства или заводской номер |
---|---|---|---|---|
Не в реестре |
Номер в Госреестре |
Наименование СИ |
Обозначение типа СИ |
Изготовитель |
Срок свидетельства или заводской номер |
---|---|---|---|---|
Не в реестре |
› Compliance & Performances
SHIELDING EFFECTIVENESS COMPLIES WITH EN 50147-1 (10 kHz - 40 GHz) Radiated emission (EMI) testing: Fully compliant with the following standards from 30 MHz to 18 (40) GHz
Radiated immunity (EMS) testing: Fully compliant with EN/IEC 61000-4-3.
› Dimensions
› Quality › About our absorbers |
||||||||||||||||||||||||||||||||||
Производитель |
Товар |
|
|
Модели и Опции |
Описание |
Цена | Заказать |
0
Модели |
HERA 3F
|
Siepel HERA 3P 30 МГц - 18 ГГц t = 3 м, ДхШхВ 7950х3400х3250 мм
|
По запросу |
